Containerized Seawater Desalination System

Product Introduction:

The containerized seawater desalination system is equipped for seasonal freshwater supply for domestic water shortages or tourism in islands where freshwater is scarce, as well as freshwater requirements in remote areas or in emergency situations. In a short time, it can quickly organize production and supply, with less investment and quick results.

The container-type reverse osmosis seawater desalination equipment adopts international advanced reverse osmosis technology and is optimized by the system. This system can effectively remove inorganic salts, heavy metal ions, organic bacteria, bacteria and other harmful components in seawater, and desalinate the seawater into high-quality water according to the national drinking water hygiene standard (GB5749-2006). The system consists of: power distribution control cabinet, dosing system, pretreatment, reverse osmosis membrane module, and backwash system.
Feature:

1. Low energy consumption: Efficient energy recovery system and overall optimized design can be configured as required to greatly reduce energy consumption.
2. Long service life: Strict process design ensures the system has a longer service life and lower maintenance costs.
3. Stable effluent water quality: Advanced water quality detection control and perfect system maintenance program ensure long-term stability of effluent water quality.
4. Highly intelligent: Develop monitoring software, and provide man-machine dialogue and mobile phone remote monitoring according to the actual needs of users.
5. The device has a centralized design, compact structure and easy installation.
6. High degree of automation, easy operation and maintenance, cleaning and maintenance without disassembly, easy management.
7. Equipment integrated design, loading and leaving, easy to transport.

Running Data:

Feed water: Seawater
Water temperature: 10~40℃
Seawater TDS: 15000~45000mg/L
Environmental temperature: 5~45℃
Elevation (max): 1000m
Output water backpressure: <0.5bar

Specification:
Product water flow: 0.25~20m3/hour
Recover rate: 30~45%
Product water TDS: ≤500~800ppm
Operate pressure: 60bar
